- Model: X2
- Electric capacity: 564K (0.56uf)
- Withstand voltage: 2100VDS
- Electric capacity range: 0.0022~4.7uf
- Color: yellow
X2 safety capacitor 564K275VAC made in china
Description
X2 safety capacitor 564K275VAC
X2 safety capacitor 564K275VAC safety capacitor is very stable, with little change over time and stability, so the input is not easily affected by environmental factors.
X2 safety capacitor 564K275VAC
| ltem | Characteristics |
|---|---|
| Reference standard | GB/T 14472（ICE 60384-14） |
| Climatic Category | 40/100/21 |
| Rated Voltage | 250V/275VAC |
| Capacitance | 0.0022µf~4.7µf |
| Capacitance Tolerance | ±10%(K);±20%(M) |
| Voltage proof | 2100VDC (2S) |
| Dissipation Factor | ≤0.001 (20°C, 10KHz) |
| Insulation Resistance
20°C，1min |
≥15000MΩ CR≤0.33µf
≥5000S CR＞0.33µf |
Film Capacitor — X2 safety capacitors
X2 0.56uf275VAC Film Capacitor
W: 32.0mm
H: 20.0mm
T:11.0mm
P±1：27.5mm
Application field
Products are widely used in power supplies, chargers, digital products, communication systems, LED drivers, intelligent systems, drones, automotive electronics Audio, Bluetooth headsets and other electronic products.
What should I pay attention to when using X2 capacitors?
1. Ensure that the safety capacitor x2 used is a standard product produced by a regular manufacturer.
Capacitors for suppressing power supply electromagnetic interference: When capacitors are used in power supply cross-line circuits to eliminate noise, not only normal voltages, but also abnormal pulse voltages (such as lightning) must be considered, which may cause capacitors to smoke Or catch fire. Therefore, the safety standards of cross-line capacitors have strict regulations in different countries, so safety-certified capacitors must be used.
2. It is not allowed to use DC capacitors as cross-line capacitors:
At the same time, it is not allowed to use DC capacitors as cross-line capacitors. The X2 type capacitor for suppressing electromagnetic interference of power supply should be suitable for occasions that will not cause electric shock when the capacitor fails, such as the power supply is connected across the line, and can withstand 2.5kV pulse voltage.
Deliver,Shipping And Serving
| Lead Time： | 3^15day(In Stock Within 3 Days) |
| Pre-Sale Service： | Various Technical Support, Sairple Support, Sales Guidance |
| Customized Service： | Capacity, Voltage, Size, Trademark |
| Special Service： | Cut Feet, Bend Feet |
| Warranty： | Unconditional replenishment |
